Tabela veličina
| PART NO. | Nominal cross-section mm² | Note | Code | Dimensions mm | Number of crimps | Conductor dia. mm | Weight/100 pcs. ~kg | PU/pcs. | |||
|---|---|---|---|---|---|---|---|---|---|---|---|
| d1 | d4 | l | Al (7 mm) | Al (wide) | |||||||
| 243R | 16 | * | 12 | 5,8 | 12,0 | 140 | 8/8 | 4/4 | 5,1 | 3,4 | 10 |
| 244R | 25 | – | 12 | 7 | 12,0 | 140 | 8/8 | 4/4 | 6,3 | 2,9 | 10 |
| 245R | 35 | – | 14 | 8,2 | 14,0 | 140 | 8/8 | 4/4 | 7,5 | 3,9 | 10 |
| 246R | 50 | – | 16 | 10,0 | 16,0 | 155 | 8/8 | 4/4 | 9,0 | 5,2 | 10 |
| 247R | 70 | – | 18 | 11,5 | 18,5 | 165 | 8/8 | 4/4 | 10,5 | 7,4 | 10 |
| 248R | 95 | – | 22 | 13,5 | 22,0 | 165 | 8/8 | 4/4 | 12,5 | 12,2 | 10 |
| 249R | 120 | – | 25 | 15,5 | 25,5 | 250 | 12/12 | 6/6 | 14,0 | 21,8 | 10 |
| 250R | 150 | – | 28 | 16,5 | 28,5 | 300 | — | 7/7 | 15,7 | 34,4 | 10 |
| 251R | 185 | – | 28 | 18,5 | 28,5 | 330 | — | 7/7 | 17,5 | 33,0 | 5 |
| 252R | 240 | – | 34 | 21,5 | 34,5 | 350 | — | 7/7 | 20,2 | 54,0 | 5 |
| 253R | 300 | – | 38 | 23,5 | 38,5 | 400 | — | 8/8 | 22,5 | 79,0 | 1 |
